Blind Solid Rivet Supplier

Publish Time: Author: Site Editor Visit: 367

product description

              Aluminium Blind Solid Rivet

Blind Solid Rivet Supplier_Blind Solid Rivet

Product Material

Cu

General Description

The conductivity of copper only second to silver and superior to all  other metals, so it  was  used as benchmarks for the conductive properties of the material. Not only copper  has excellent electrical conductivity, but also high melting point (1083 ℃), good mechanical properties, corrosion resistance,  reliable for working  , long life for using , it  becomes the most widely used  conductive material.

Application Scop

The electrical contact componentscan be widely used in switches, relays, thermostats, contactors, disconnector,controllers, timers and other low-voltage apparatus.

MaterialProperties

Cu Content(wt.%) Density(g/cm³) ElecResistivity (µΩ·cm) Hardness HV (MPa) TensileStrength(MPa) Elongation(%)
≥99.90 8.89 ≤0.0177 ≥65 ≥295 ≥3



                         Contact Tips

Blind Solid Rivet Supplier_Contact Tips

Product Material

Alloy Material Inner Oxidized is widely used within method to make Oxidized Electrical,including AgSnO2, AgSnO2InO3, AgZnO2, AgCu0,AgCdO,etc. Alloy oxidation contactproducts are widely used in low-voltage electrical appliances

General Description

1.Inner Oxidized Electrical Contact owns excellent consistency ,tiny Oxidized material particle ,arc corrosion resistance and long electricity life.

2.Adding nickel and thulium to AgSnO2,AgSn02In2O3,AgZnO2,AgCuO,AgCdO,etc with the technology of low temperature high pressure oxidized takes effect on making grain tiny ,dispersion and aggrandizement ,consequently improves the mechanical strength ,ameliorate fusion ,arc corrosion resistance and abrasion.

3.Adopting melting pulverization and pre-oxidized manufacturing methods can make high quality contact material with the advantage of grain thin and organization uniformity ,no defection in microcosmic structure ,eliminating oxide leanness area.

Application Scope

1.AgSnO2,AgSnO2In03series : Widely used in AC Contactor (CJ20,CJ40,3TF ,ETC)Power AC Switch (≧50KW),DC Contactor ,AC \DC Power Relay  ,Automobile and low voltage circuit breaker.

2.AgZnO2 series: Widely used in low voltage circuit breaker with rating ,electricity within 200A(such as DZ15 series ,especially omnipotence breaker )drive socket, protective socket, AC Relay  DZ5L series breaker etc. Some large capacity switches also use AgZnO materials such as ME omnipotence breaker.

3.AgCdO series:Widely used in large capacity relay,contactor,ac-ds switch , medium and small capacity circuit breaker,particularly used for large caoacity ac contactor.



Company Profile

Wenzhou Saijin Electrical Alloy Co.,Ltd(Saijin for short) specializes in producing all kinds of contact rivets,contact points,contact components,electrical accessories and silver alloy wires.

Sajin use the material Cd free which meets the Eu RoHS&REACH requirement.

Saijin has obtained ISO9001:2015 which assure stable quality.

Saijin has owned strong R&D department,we were awarded with Zhejiang Province scientific and technological enterprise since 2016.

Saijin cooperating with Schneider,Haier,Panasonic,Chnt,Bahra Cables,Apator,FEB,Amper Auto etc.
